Self lubricating low-noise Peek bearings

Name: Self lubricating low-noise Peek bearings
Brand: Dongguan Pruisi Plastic Materials Co., Ltd
SKU: PEEK 1000
Price: 2.00 USD
Availability: InStock

Brand Name:	PRES
Model Number:	PEEK 1000
MOQ:	100pcs
Price:	2-3
Payment Terms:	D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	10000 piece per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ROHS REACH

Material:

PEEK Resin

Color:

Natural,Black, Customized

Density:

1.31

Product Name:

Self Lubricating Low-noise Peek Bearings

Feature:

High Wear Resistance,abrasion Resistance,Durable,260℃ Working Temperature

Application:

Automotive, Mechanical Manufacturing, Aerospace, Industrial Automation, Medical Equipment

Sample:

To Be Negotiated,free Sample

Shape:

Customized Bearings

Packing:

Inner In Poly Bags,wooden Case

Packaging Details:

Inner In Poly Bags,wooden case

Supply Ability:

10000 piece per month

Highlight:

Self Lubricating Peek Bearings

Low Noise Peek Bearings

Low noise Peek bearings

Product Description

Self lubricating low-noise Peek bearings

Self lubricating low-noise PEEK bearings have many advantages. PEEK material itself has excellent self-lubricating properties, without the need for additional lubricating oil, reducing maintenance costs and environmental pollution. During operation, it can effectively reduce the friction coefficient and improve the service life of the bearing. At the same time, the bearing generates extremely low noise during operation, providing a quiet working environment for the equipment. PEEK bearings also have characteristics such as high temperature resistance, corrosion resistance, and high strength, which can adapt to various harsh working conditions. It can play an important role in fields such as precision machinery, aerospace, and automotive, and is a high-performance bearing solution.

send me your drawings,and we can design molds and injection for you

PEEK Parameters
NO.	Item no.	Unit	PEEK-1000	PEEK-CA30	PEEK-GF30
1	Density	g/cm3	1.31	1.41	1.51
2	Water absorption (23℃ in air)	%	0.2	0.14	0.14
3	Tensile strength	MPa	110	130	90
4	Tensile strain at break	%	20	5	5
5	Compressive stress(at 2% nominal strain)	MPa	57	97	81
6	Charov impact strength(unnotched)	KJ/m2	No break	35	35
7	Charov impact strength(notched)	KJ/m2	3.5	4	4
8	Tensile modulus of elasticity	MPa	4400	7700	6300
9	Ball indentation hardness	N/mm2	230	325	270
10	Rockwell hardness	--	M105	M102	M99
